17 pollici di un produttoredisplay leggibile alla luce del solesoluzione per stazione di servizio all'aperto

Nell’ondata di trasformazione digitale delle stazioni di servizio, uno schermo chiaramente visibile è il collegamento centrale tra utenti e servizi. RisingStar 17 pollici schermo esterno ad alta luminosità, questo modulo di visualizzazione dotato di schermo rigido IPS di qualità industriale, con una luminosità massima di 5000nits e protezione IP65, ha sempre un tasso di guasto estremamente basso dello 0,1% e un angolo di visione completo di 89 °, garantendo che tutti i dati siano ancora chiaramente visibili in ambienti estremi, indipendentemente dal sole ardente a mezzogiorno o dalla pioggia intensa.

Valutazione dei clienti:
La cosa più sorprendente del display della stazione di servizio da 17 pollici è la sua leggibilità alla luce del sole: quando il sole pomeridiano locale è direttamente esposto, la saturazione dello schermo può ancora raggiungere il 92% NTSC, il feedback dei clienti è “chiaro come guardare uno schermo di un telefono cellulare”.

Perché i clienti scelgono RisingStar

1. Ottime prestazioni di visualizzazione all'aperto

Luminosità ultra alta e interferenza della luce ambiente
La luminosità massima dello schermo raggiunge 5000nits, supporta la regolazione dinamica 2500-4500nits e la tecnologia di retroilluminazione diretta garantisce che l'immagine sia chiara e visibile in ambienti di forte luce (come la luce del sole di mezzogiorno), risolvendo i problemi di riflessione e abbagliamento delle attrezzature esterne.

La tecnologia ad alto contrasto e ad ampia gamma di colori migliora lo stratificazione dell'immagine, si adatta alla complessa interfaccia di interazione dei dati del dispensatore di carburante e riduce gli errori visivi.

All-weather environmental adaptability‌
Passed industrial-grade wide temperature certification (-20℃ to 60℃), each Each device undergoes an 8-hour extreme temperature cycle test and a 24-48-hour continuous operation test before leaving the factory to ensure that the brightness does not drop at high temperatures and that it starts quickly at low temperatures.
The IP65 protection level is matched with a fully waterproof whole machine design, which is dustproof, rainproof, and corrosion-resistant, meeting the needs of high-pollution, oil-rich scenes such as gas stations.

2. Industrial-grade reliability and lightweight design

Long life and low maintenance cost ‌
The screen life is up to 30,000 hours, and the backlight module adopts anti-attenuation technology. After 20,000 hours of continuous operation, the brightness retention rate is greater than 90%, reducing the frequency of equipment replacement.
The all-aluminum frame structure is 30% lighter than the traditional iron shell, reducing the overall load of the equipment, while having excellent heat dissipation and anti- Vibration resistance.

Modularization and compatibility optimization ‌
Provide open modules, fully waterproof whole machines and other forms, support LVDS interface protocol and capacitive/infrared touch integration, and adapt to various terminals such as gas dispensers and advertising machines for rapid modification.

Ultra-thin body, meeting the needs of compact space installation and ultra-large field of view.

3. Technological innovation and cost advantage ‌

Balance between energy saving and stability ‌
Dynamic energy-saving technology reduces power consumption by 30%, combined with intelligent temperature control system to avoid overheating risks during high-brightness operation and extend component life.

Direct backlight solution reduces optical loss, and with automatic light adjustment function, automatically reduces brightness to a comfortable range at night to save energy.

Strict quality control and fast service Service response ‌
Each device has been tested for salt spray, vibration, high and low temperature shock, and the failure rate is less than 0.1%.
The national service network covers customized solutions and 48-hour emergency maintenance support.

Analysis of the core technology of this 17-inch screen

1. Display performance and optical characteristics

High resolution and visual experience ‌

Adopting 1280×1024 (SXGA) resolution, pixel density 86PPI, display area up to 376.32×301.056mm, it is suitable for the strict requirements of data clarity in industrial scenes.
IPS full viewing angle technology (89°/89°/89°/89°), with 1200:1 contrast ratio and 72% NTSC color gamut ensures color consistency and readability of the picture, and reduces color deviation caused by viewing angle deviation.

Optical optimization design‌

Matte treatment (Haze 25%) + 3H hard coating effectively suppresses reflection and glare, and adapts to outdoor environments with strong light or multiple light sources.

250nits typical brightness (backlight is 19S2P WLED), balances energy consumption and visibility, and meets the display needs of indoor industrial equipment.

2. Performance and response speed

Refresh rate and dynamic compensation‌
Supports 75Hz basic refresh rate, and realizes 75Hz dynamic interpolation (60Hz input) through built-in MEMC circuit, reduces screen smear, and adapts to real-time monitoring or dynamic data display scenarios.
Response time 14ms (G to G), reduce the delay of high-speed screen switching, and improve the interaction fluency of industrial control interface.

III. Industrial-grade reliability design

Environmental adaptability

The operating temperature range is 0~50°C, and the storage temperature is extended to -20~60°C. It has passed the wide temperature certification and is suitable for stable operation in extreme environments.

The backlight life is 30,000 hours (WLED), combined with low power consumption design (5.0V power supply), which reduces the long-term maintenance cost.

Lightweight structure and compatibility

Ultra-thin body design (10.4mm thickness), weighing only 1.46Kg, using an all-aluminum frame to enhance heat dissipation and shock resistance.

Typical application scenario verification

Outdoor refueling machine: 17 inch industrial-grade LCD + AG glass full bonding process, anti-oil corrosion, suitable for payment terminals and information prompt screens.

Gas station 17 inch display leggibile alla luce del sole parameter table
