75 Inch High Brightness Outdoor Digital Display
Key Features
High brightness 2500 nits
LED backlight for superior illumination
Sunlight readable for perfect outdoor visibility
Automatic brightness adjustment via light sensor
LCD blacking defect free technology
Low power consumption design
Backlight MTBF: 50,000 hours
Specifications
| Model Name | RS750HNX01-A01-BK |
|---|---|
| Screen Size | 75" |
| Display Area (mm) | 1649.66 (W) × 927.94 (H) |
| Brightness | 2500 cd/m² |
| Resolution | 3840 × 2160 (4K UHD) |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1200:1 |
| Response Time (Typical) | 8 ms (Tr/Td) |
| Viewing Angle | 89/89/89/89 (Min., CR≥10) |
| Display Colors | 16.7M |
| Operating System | Android 11 (Optional) |
| RAM / ROM | 4G / 32G (Optional) |
| Speaker | 5W × 2 |
| Glass | 5 mm front anti-reflection glass, IK10 impact resistant |
| Touch Type | Capacitive touch, 10-point (Optional) |
| Network Options | WiFi / Ethernet / 4G (Optional) |
| Input Power | AC 100–240V |
| Power Consumption | < 800W |
| Cooling System | Passive heat dissipation (fanless) |
| Input Interfaces | Optional (HDMI ×1, RJ45 ×1, USB ×2, AC ×1) |
| Dimensions (mm) | 1730.6 × 1009 × 104.5 |
| Mounting | 400 × 600 mm, 4 × M8 (Max depth: 12 mm) |
| Weight (Net) | TBD |
| Ingress Protection | IP66 (Fully waterproof and dustproof) |
| Shell Color | Black |
| Operating Temperature | -20°C ~ 50°C |
| Storage Temperature | -20°C ~ 60°C |
