43 Inch Outdoor High Brightness Air Cooled Display
Model Name: RS430HNX05-A01-BK
Key Features
High brightness 2500nits
LED Backlight
Sunlight Readable
Automatic brightness adjustment via light sensor
LCD Blacking Defect Free
Low Power Consumption
Backlight MTBF: 50,000 hours
Specifications
| Item | Description |
|---|---|
| Screen Size | 43" |
| Display Area (mm) | 941.18 (W) × 529.42 (H) |
| Brightness | 2500 cd/m² |
| Resolution | 1920 × 1080 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1200:1 |
| Response Time (Typical) | 10 ms (Tr/Td) |
| Viewing Angle | 89/89/89/89 (Min.) (CR≥10) |
| Display Colors | 16.7M |
| Operating System (Optional) | Android 11 |
| RAM (Optional) | 4GB |
| ROM (Optional) | 32GB |
| Speaker | 5W × 2 |
| Glass | 5mm tempered glass, front anti-reflection, IK10-rated |
| Touch Type (Optional) | 10-point capacitive touch |
| Network (Optional) | Wi-Fi / Ethernet / 4G |
| Input Power | AC100–240V |
| Power Consumption | ＜200W |
| Cooling System | Intelligent fan cooling (auto start at >35°C) |
| Input Interface (Optional) | HDMI ×1, RJ45 ×1, USB ×2, AC ×1 |
| Dimensions (mm) | 1011 × 599.8 × 93.5 |
| Mounting | 400 × 400 mm, 4-M8, Max Depth = 10 mm |
| Weight (Net) | TBD |
| Ingress Protection (IP) | IP66 |
| Shell Color | Black |
| Operating Temperature | -20°C ~ 50°C |
| Storage Temperature | -20°C ~ 60°C |
